Introduction
SFR-M series LV(low voltage) dynamic harmonic mitigation reactive compensation module is designed for solve the problem of harmonic and power factor in the situation of serious harmonic pollution in 0.4kV low voltage power distribution network. It is used as an integrated reactive power compensation module with functions of power factor enhancement, effective harmonic suppression, reduction of line loss and improvement of power quality.
